| Number of port |
GPON |
4 port (SFP, SC PC Type) |
| Ethernet |
4 port 1000Base-X (SFP, SX/LX/ZX Type) |
| Console |
Wireless console(Bluetooth) |
GPON
Features
|
Wavelength(UL / DL) |
1310nm / 1490nm |
| Dying Gasp |
Message arise when power problem arise |
| SF/SD Monitoring |
SF(Signal Failure), SD(Signal Degrade) monitoring features |
Rx Optical Level check and
Low/High Threshold alarm |
Rx Optical Level(1490nm) measure and check features
RX Optical Threshold Low/High alarm features |
| Security features |
MAC Limit features
AES encryption features
Abnormal traffic blocking features |
| System memory |
512MB DRAM, 1GB Flash Memory |
| Switching features |
32K MAC entries, 4,096 Active VLANs
802.1P Priority Queuing (8 Level Priority Queues)
802.1p Marking
SPQ(Strict Priority Queuing), DWRR(Deficit Weighted Round Robin), SPQ+DWRR
1M unit Ingress, Egress Rate Limiting
Spanning Tree(STP, RSTP), MTU 9K byte
Link Aggregation
IGMP Snooping(v1, v2)
IGMP Join-group Limit /Filter |
| Operation and management features |
SSH(Security Shell), telnet, SNMP, Syslog features
System Monitoring(CPU load, Memory Usage, Gateway, Processor)
RADIUS, TACACS
Operation status monitoring through external LED
Remote upgrade features through OLT |
| Dimension |
Height x width x dept : 180mm x 470mm x 240mm
Weight : 9.8kg
Operation temperature : -20¡É~50¡É
Store temperature : -40¡É~70¡É
Operating humidity : 0%~95%
Power : AC 220V |
